Product Details:
|
| Special Use: | Wear Resistant Steel | Application: | Stone Crusher,Engineering Machinery，excavator |
|---|---|---|---|
| Technique: | Hot Rolled | Standard: | ASTM,AISI,JIS,GB,DIN |
| Length: | 1000-12000mm，regular 6m/12m | Hardness: | 58-65HRC |
| Surface: | Can Painted As Your Requirement | Steel Mills: | Laisteel, Xingcheng,Xinyu,Baosteel,liansteel Ect |
| Thickness: | 3-200mm | Stock: | 2000tons |
| High Light: | Wear Resistant Steel Plate Ar400,ASTM Wear Resistant Steel Plate,2000mm Wear Resistant Steel Plate |
||
Product Description
Wear Resistant Steel Plate refers to special plate products designed for use under large-area wear conditions.
Wear-resistant steel plate has high wear resistance and good impact performance. It can be cut, bent, welded, etc., and can be connected to other structures by welding, plug welding, bolt connection, etc., which saves time in the process of repairing the site. , convenience, etc.
Size Range :
Thickness 3-120mm Width :1000-2200mm Length :3000-12000mm
Wear-resisting Steel Comparison Table
| GB | WUYANG | JFE | SUMITOMO | DILLIDUR | SSAB | HBW | Delivery status |
| NM360 | WNM360 | JFE-EH360A | K340 | —— | —— | 360 | Q+T |
| NM400 | WNM400 | JFE-EH400A | K400 | 400V | HARDOX400 | 400 | Q+T |
| NM450 | WNM450 | JFE-EH450A | K450 | 450V | HARDOX450 | 450 | Q+T |
| NM500 | WNM500 | JFE-EH500A | K500 | 500V | HARDOX500 | 500 | Q+T |
| NM550 | WNM550 | —— | —— | —— | HARDOX550 | 550 | Q+T |
| NM600 | WNM600 | —— | —— | —— | HARDOX600 | 600 | Q+T |
NM400 Chemical Property
| GRADE | Chemical Property(Quality Percent)/% | ||||||||||||||
| C | Si | Mn | P | S | Cr | Ni | Mo | Ti | Bta | AIs | CEV | ||||
| ≤ | ≥ | ≤ | |||||||||||||
| NM400 | 0.3 | 0.70 | 1.60 | 0.025 | 0.010 | 1.0 | 0.70 | 0.50 | 0.050 | 0.0005~0.006 | 0.010 | 0.55 | |||
| a Bt stands for Boron content. | |||||||||||||||
NM400 Mechamical Property
| GRADE |
THICK mm |
TENSIBLE STRENGTH Rm MP a |
YIELD STRENGTH A50 % |
—20℃ IMPACT TEST AKv / J |
HBW |
| NM400 | 3~80 | ≥1200 | ≥10 | ≥24 | 370~430 |
| Tensile strength, elongation and impact energy as the special requirements of performance, such as customer did not indicate in the contract, the only guarantee the brinell hardness. | |||||
In order to meet the various needs of customers, we set up our own machining center.we have our own workshop, we can supply one
stop service:
Contact Person: Mr. Ethan
Tel: +8619963522667
Fax: 86-19963522667
Applications
